The robot welding gun is provided in anintegrated structure, with a welding transformer installed at the tail of thewelding gun, which reduces the current loss while makes the transformer smallerin size. The opening of robot welding gun equipped with a high-precision servomotor and a driver can be adjusted according to the condition of the workpiece.The opening degree of welding gun is minimized without impacting the workpiece,so that the opening and closing time of the welding gun is saved, and the cycleof each welding point is greatly reduced as well.

With its stable and reliable action aswell as high repeatability precision, the robot welding gun can improve thewelding quality, ensure the stable welding quality, greatly shorten the workcycle, and improve the labor productivity. It can replace the heavy manualwork, and ensure that product is of high quality. It produces low noise, and isenvironmentally friendly and energy saving.

The main body of the welding gun is made of high-strength aluminum plate, whichis light in weight, good in strength and excellent in conductivity.

The welding gun is light in weight and stable in structure, and the 4-waycooling water used in its waterway can provide superior cooling effect. Whenrobots of the same specifications are used, such welding gun can be made largerin size to better meet the welding needs.

With its stable and reliable action as well as high repeatability precision,the intermediate frequency servo robot welding gun can improve the weldingquality, ensure the stable welding quality, greatly shorten the work cycle, andalso improve the labor productivity. It can replace the heavy manual work andensure high quality of the product. It produces low noise and is alsoenvironmentally friendly and energy saving.

Compared with the traditional compressed air drive, it is provided with thecombination of servo motor and electric cylinder as its drive device, which ismore energy-saving and environmentally friendly, and may provide more stablepower. The stroke as well as the welding pressure can also be adjusted as required.

The transformer adopts the intermediatefrequency inverter DC technology, and is cooled by the water cooling method. Itis equipped with three temperature control switches to detect the primary coil,secondary coil and diode respectively. Compared with the power frequencytransformer, the transformer is lighter in weight, smaller in size, higher incurrent, more energy-saving and environmentally friendly, and more stable inperformance.

The main body of the welding gun is madeof high-strength aluminum plate, which is light in weight, good in strength andexcellent in conductivity.

The welding gun is light in weight andstable in structure, and the 4-way cooling water used in its waterway hassuperior cooling effect. When robots of the same specifications are used, suchwelding gun can be made larger in size to better meet the welding needs.
