Spring balancer:RW-40Kg
ProductDteails





RW series springbalancer is an auxiliary tool designed and manufactured by our company and usedin connection with operation tools.

With the energyaccumulated by the coil spring, this series of products keep the suspendedoperation tools in weightless state, which thus greatly reduces the laborintensity of the workers. This series of products are suitable for assemblylines and occasions with various fixed positions, intensive workload, heavyoperating tools and long duration of using tools, and are widely used in thefields of automobile manufacturing, household appliances and machinemanufacturing, etc. It can be used not only in assembly lines or occasions withfixed work stations, but also in the occasions using manual tools and liftingequipment, and can also be used as auxiliary tools for lifting workpieces. Whenit is necessary to move the heavier workpieces from and to the workplace formultiple times, it can relieve the intensity of labor by the lifting power ofbalancer.

This series ofproducts are available in several models as per different loads:

RW-3kg, RW-5kg,RW-9kg, RW-15kg, RW-22kg, RW-30kg, RW-40kg, RW-50kg, RW-60kg, RW-70kg, RW-80kg,RW-90kg, RW-100kg, RW-120kg, RW-140kg, RW-160kg, etc. The spring balancers ofRW-3kg and RW-5kg also have the feature of locking at any position in the upand down sliding process.


Related parameters




Molde

Balanced load

stroke

Weight

H

W

B

RW-3KG

13 KG

3.0M

1.4KG

260 mm

150 mm

65 mm

RW-5KG

35 KG

3.0M

1.4 KG

260 mm

150 mm

65 mm

RW-9 KG

59 KG

1.3M

3.9 KG

432 mm

180 mm

137 mm

RW-15 KG

915 KG

1.3M

4.2 KG

432 mm

180 mm

137 mm

RW-22 KG

1522 KG

1.5M / 2.0M

7.7 KG

499 mm

218 mm

159 mm

RW-30 KG

2230 KG

1.5M / 2.0M

8.1 KG

499 mm

218 mm

159 mm

RW-40 KG

3040 KG

1.5M / 2.0M

10.1 KG

546 mm

220 mm

200 mm

RW-50 KG

4050 KG

1.5M / 2.0M

10.5 KG

546 mm

220 mm

200 mm

RW-60 KG

5060 KG

1.5M / 2.0M

11.5 KG

546 mm

220 mm

200 mm

RW-70 KG

6070 KG

1.5M / 2.0M

11.8 KG

546 mm

220 mm

200 mm

RW-80 KG

7080 KG

1.5M / 2.0M

12.1 KG

546 mm

220 mm

200 mm

RW-90 KG

7090 KG

1.5M / 2.0M

24.2 KG

540 mm

325 mm

320 mm

RW-100 KG

80100 KG

※1.5M / 2.0M

24.5 KG

540 mm

325 mm

320 mm

RW-120 KG

100120 KG

※1.5M / 2.0M

30.2 KG

550 mm

335 mm

360 mm

RW-140 KG

120140 KG

※1.5M / 2.0M

30.8 KG

550 mm

335 mm

360 mm

RW-160 KG

140160 KG

※1.5M / 2.0M

31.2 KG

550 mm

335 mm

360 mm

RW-180 KG

160180 KG

※1.5M / 2.0M

31.5 KG

550 mm

335 mm

360 mm



Attention: "※" is the default standard. If you need a 2.0M itinerary, please specify your requirements when placing an order.
