Series 2 X-type integrated welding gun
ProductDteails


Series 2integrated suspension spot welding gun has a protective plate structure designat its tail, with large cylinder pressure output and small volume of themachine. Furthermore,two types of transformers – the mediumfrequency and power frequency transformers are available, which canbe used in combination as per the welding requirements.

The integrated suspension spot welding gun is made by the assembling process, wherethe transformer and the gun arm are integrated and fixed on the rotating disc.The inner ring and the outer ring of the rotating disc are connected by abearing structure, which has the characteristics of flexibility and stability.The welding gun can rotate by 360 degrees through the rotating disc, and therotating disc is provided with a locking mechanism which can be locked at anyangle, thus effectively meeting some specific welding postures. After thewelding is completed with specific postures, the welding gun can rotatenormally once unlocked.

The body of welding gun is made with hard die casting process, and has compactstructure, high density, high strength and few defects such as sand holes andair holes.

Solenoid valves and other outsourced parts are well-known foreign brands withstable performance and long service life.

The cable at the tail of the welding gun is fixed by a wire harness frame,which can effectively prevent the cable from friction damage when the weldinggun twist.
